Send InquiryA9N18363-circuit breaker, EasyPact CVS800N, 50kA at 415VAC, ETS 2.3, 800A, 4P 3d
Price 2852.0 INR/ Piece
MOQ : 2 Pieces
A9N18363-circuit breaker, EasyPact CVS800N, 50kA at 415VAC, ETS 2.3, 800A, 4P 3d Specification
- Rated Short Circuit Breaking Current
- 10000 A Ampere (A)
- Rated Short Circuit Making Current
- 10000 A Ampere (A)
- Poles Number
- 2
- Rated Frequency
- 50/60 Hz Hertz (HZ)
- Warranty
- 1 YEAR
- Curves
- C curve
- Temperature Protection
- -40 85 C Celsius (oC)
- Usage & Applications
- Distribution
- Weight
- 0.41 kg Kilograms (kg)
- Rated Voltage
- 500 V AC Volt (V)
- Operating Temperature
- -25 70 C Celsius (oC)
- Frequency
- 50/60 Hz Hertz (HZ)
- Rated Current
- 125A Ampere (amp)
A9N18363-circuit breaker, EasyPact CVS800N, 50kA at 415VAC, ETS 2.3, 800A, 4P 3d Trade Information
- Minimum Order Quantity
- 2 Pieces
- Payment Terms
- Paypal, Cash Advance (CA), Cash in Advance (CID), Cheque
- Supply Ability
- 32 Pieces Per Week
- Delivery Time
- 4 Days
- Sample Available
- No
- Packaging Details
- RAIP WITH CARTUN
- Main Export Market(s)
- Asia
- Main Domestic Market
- All India
About A9N18363-circuit breaker, EasyPact CVS800N, 50kA at 415VAC, ETS 2.3, 800A, 4P 3d
This Acti9 C120N is a low voltage multistandard miniature circuit breaker (MCB). It is a 2P circuit breaker with 2 protected poles, 125A rated current and C tripping curve. The rated short circuit breaking capacity goes up to 10000A at 230VAC to 400VAC conforming to EN/IEC 60898-1 standard and 10000A at 230VAC to 400VAC conforming to EN/IEC 60898-1 standard. It complies with both industrial standard EN/IEC 60898-1 and residential standard EN/IEC 60947-2. This miniature circuit breaker protects circuit against short circuit and overload current. The presence of green strip guarantees contact open physically and allows work to be carried out safely on the downstream circuit. It has good overvoltage withstand capacity. The product is designed to offer a high industrial performance level It has an electrical endurance going up to 5000 cycles and a mechanical endurance going up to 20000 cycles. The Ue operational voltage is going from 380VAC to 415VAC. The Ui rated insulation voltage is 500VAC. Its limitation class 3 (according to EN/IEC60898-1) improves downstream circuit protection cost. The product can be clipped on a DIN rail. Its width is 6 pitches of 9mm. Pollution degree is 3. Overvoltage category is IV. The product colour is white (RAL9003). The dimensions are (W) 54mm x (H) 81mm x (D) 73mm. The weight is 0.41kg. It has an IP20 degree of protection (as per IEC/EN 60529) on its terminals. The operating temperature is -25C to 70C. The storage temperature is -40C to 85C.
Tell us about your requirement
Price:
Quantity
Select Unit
- 50
- 100
- 200
- 250
- 500
- 1000+
Additional detail
Mobile number
Email
More Products in Circuit Breaker Category
LV525332-Miniature circuit-breaker, Acti9 C120N, 3P, 125 A, C curve, 10000 A (IEC 60898-1), 10 kA (IEC 60947-2)
Price 9853.1 INR / Piece
Minimum Order Quantity : 1 Piece
Operating Temperature : 25 70 C Celsius (oC)
Warranty : 1 YEAR
Rated Current : 200 A Ampere (amp)
Weight : 1.7 kg Kilograms (kg)
LV516333-circuit breaker EasyPact CVS160F, 36 kA at 415 VAC, 160 A rating thermal magnetic TM-D trip unit, 3P 3d
