ATV340U40N4E-variable speed drive, Altivar Machine ATV340, 4kW, heavy duty, 400V, 3 phases, Ethernet

Name: ATV340U40N4E-variable speed drive, Altivar Machine ATV340, 4kW, heavy duty, 400V, 3 phases, Ethernet
Brand: META AUTOMATION SOLUTIONS
Price: 42509.0 INR
Availability: InStock

Price 42509.0 INR/ Piece

Get a Price/Quote

MOQ : 12 Pieces

ATV340U40N4E-variable speed drive, Altivar Machine ATV340, 4kW, heavy duty, 400V, 3 phases, Ethernet Specification

Connector Type
3 RJ45

IP Rating
IP20

Overheating Protection
YES

Mounting Type
WALL MOUNT

Product Type
Variable speed drive

Power Rating
4KW

Application
Machine

Protection Level
IP54

Frequency (MHz)
60 Hertz (HZ)

Dimension (L*W*H)
270 Millimeter (mm)

Weight
2.5 Kilograms (kg)

Rated Voltage
400 Volt (V)

Warranty
1 YEAR

Input Voltage
24 Volt (V)

Phase
THREE PHASE

Frequency
60 Hertz (HZ)

Rated Current
9.3 Ampere (amp)

Connection Type
Line side: screw terminal 1.5...4 mm /AWG 14...AWG 12 DC bus: screw terminal 4...6 mm /AWG 12...AWG 10 Motor: screw terminal 1.5...4 mm /AWG 14...AWG 12 Control: screw terminal 0.2...2.5 mm /AWG 24...AWG 12

ATV340U40N4E-variable speed drive, Altivar Machine ATV340, 4kW, heavy duty, 400V, 3 phases, Ethernet Trade Information

Minimum Order Quantity
12 Pieces

Payment Terms
Paypal, Cash Advance (CA), Cash in Advance (CID), Cheque

Supply Ability
32 Pieces Per Week

Delivery Time
5 Days

Sample Available
No

Sample Policy
Within a certain price range free samples are available

Main Export Market(s)
Asia

Main Domestic Market
All India

About ATV340U40N4E-variable speed drive, Altivar Machine ATV340, 4kW, heavy duty, 400V, 3 phases, Ethernet

This Altivar 340 variable speed drive can feed 3-phase synchronous and asynchronous motors in open and closed loop control. Altivar Machine ATV340 drives are sized heavy duty as standard. It works at a rated power up to 4kW / 5hp and a rated voltage from 380V to 480V AC. ATV340 has been designed to meet the needs of applications for harsh environments, such as vibration, shock and non-conductive dust and where high temperature resistance up to 60 C is needed. This product integrates Modbus serial line communication protocols as standard. This drive features multi-protocol Ethernet embedded, it consists of Ethernet IP and Modbus TCP communication interfaces. it weighs 2.2kg and its dimensions are, 85mm wide, 270mm high, 232.5mm deep. ATV340 incorporates functions and features suitable for the most common applications, including packaging, material handling, material working, hoisting. It conforms to international standards IEC/EN 61800-5-1 and IEC/EN 61800-3 (immunity and conducted and radiated EMC emissions), IEC 60721-3, IEC 61508, IEC 13849-1. It is also CE, UL, CSA, and TV certified. Accessories and options (encoder interface modules, I/O expansion modules, communication modules, braking resistors, line chokes, additional EMC filters) are available with Altivar Machine ATV340 drives, depending on the drive rating. It is designed to be mounted in vertical position (+/- 10 ) on a panel, thanks to 4 fixing holes. It is fully integrated inside Schneider Electrics EcoStruxure Machine through DTM. It is possible to configure, control, and diagnose ATV340 drives directly in SoMachine and SoMove software by means of the same software brick (DTM).
