BSH1004P11A2A-servo motor BSH, Lexium 05, 9.31N.m, 1500rpm, 100mm, keyed shaft, Sincos single turn, without brake, IP50

Name: BSH1004P11A2A-servo motor BSH, Lexium 05, 9.31N.m, 1500rpm, 100mm, keyed shaft, Sincos single turn, without brake, IP50
Brand: META AUTOMATION SOLUTIONS
Price: 75329.0 INR
Availability: InStock

Price 75329.0 INR/ Piece

Get a Price/Quote

MOQ : 1 Piece

BSH1004P11A2A-servo motor BSH, Lexium 05, 9.31N.m, 1500rpm, 100mm, keyed shaft, Sincos single turn, without brake, IP50 Specification

Rated Voltage
480 Volt (V)

Poles Number
8

Current Type
6.2A

Power Rating
2600W

Voltage
480 Volt (v)

Rated Frequency
8 Hertz (HZ)

Ambient Temperature
120 Celsius (oC)

Product Type
Servo Motor

Output Power
2600 Watt (w)

Frequency (MHz)
8 kHz Hertz (HZ)

Protect Feature
Other

Phase
Three Phase

Efficacy
Other

Speed
6000 RPM

Starting Type
Electric Start

Power
3.64W Watt (w)

Dimension (L*W*H)
3.5mm (Depth) x 95mm (Diameter) with 115mm Millimeter (mm)

Operating Temperature
100 Celsius (oC)

Weight
9.5 Kilograms (kg)

Warranty
1YEAR

Rated Current
6.2 Ampere (amp)

Shaft Diameter
19MM Millimeter (mm)

Mounting Type
International standard flange

BSH1004P11A2A-servo motor BSH, Lexium 05, 9.31N.m, 1500rpm, 100mm, keyed shaft, Sincos single turn, without brake, IP50 Trade Information

Minimum Order Quantity
1 Piece

Payment Terms
Paypal, Cash Advance (CA), Cash in Advance (CID), Cheque

Supply Ability
15 Pieces Per Week

Delivery Time
4 Days

Sample Available
No

Main Export Market(s)
Asia

Main Domestic Market
All India

About BSH1004P11A2A-servo motor BSH, Lexium 05, 9.31N.m, 1500rpm, 100mm, keyed shaft, Sincos single turn, without brake, IP50

This product is part of the Lexium range, an offer of motion servo drives and servo motors. The 8-pole AC servo motor features a low moment of inertia with maximum mechanical speed of 6000RPM and IP54 parallel keyed shaft without holding brake. It is equipped with a single-turn (131072 points/turn) SinCos Hiperface high-resolution absolute encoder giving an angular shaft position precise to less than 1.3 arc minutes. BSH servo motor satisfies requirements for precision and high dynamic performance, due to the low rotor inertia. It is compact, and offers a high power density. It is a synchronous servo motor with a supply voltage of 480V, a continuous stall current of 6.2A and a maximum continuous power of 3.64W. The shaft dimensions are 24mm (Diameter) x 50mm (Length). It is furnished with rotatable right-angled connectors for electrical connection. It is an IP50 rated product. Its dimensions are 276.5mm (Length) x 100mm (Width), centring collar dimensions are 3.5mm (Depth) x 95mm (Diameter) with 115mm circle diameter of the mounting hole. It weighs 9.5kg. This product is compatible with Lexium 32, Lexium 05 and Lexium 15 servo drives. It supports international standard 100mm flange mount with a natural convection cooling system. Encoder gives the absolute position of the motor so that flows can be synchronized and sends data from the servo motor to the servo drive, which provides automatic identification of the motor when the servo drive starts. BSH servo motor with a 3-phase stator and neodymium iron boron (NdFeB) magnets. Casing with RAL 9005 opaque black paint protective coating. 4-point axial mounting flange. Cables and connectors to be ordered separately.
