Power Meter-METSEEM6436HCL10RS
4737.0 INR/Piece
Product Details:
- Usage & Applications Power monitoring Energy monitoring
- IP Rating IP51 front: conforming to IEC 60529 IP30 body: conforming to IEC 60529
- Rated Voltage 44...300 V AC 45...65 Hz 44...300 V DC Volt (V)
- Accuracy Current +/- 0.5 % Voltage +/- 0.5 % Frequency +/- 0.05 % Power factor +/- 0.01 Reactive power +/- 2 % Active power +/- 1 % Apparent power +/- 1 % Active energy +/- 1 % Reactive energy +/- 2 % Apparent energy +/- 1 % %
- Frequency 50 Hz 60 Hz Hertz (HZ)
- Rated Current 5 A 1 A Ampere (amp)
- Power Rating 4 VA at 240 V between phase and neutral
- Click to View more
X
Power Meter-METSEEM6436HCL10RS Price And Quantity
- 4 Piece
- 4737.0 INR/Piece
Power Meter-METSEEM6436HCL10RS Product Specifications
- Mechanical dimensions are 96 mm in width, 96 mm in height and 90 mm in depth. Millimeter (mm)
- IP51 front: conforming to IEC 60529 IP30 body: conforming to IEC 60529
- 300 g Grams (g)
- 44...300 V AC 45...65 Hz 44...300 V DC Volt (V)
- 50 Hz 60 Hz Hertz (HZ)
- 5 6000 mA Megaampere ( MA)
- Power monitoring Energy monitoring
- 5 A 1 A Ampere (amp)
- Current +/- 0.5 % Voltage +/- 0.5 % Frequency +/- 0.05 % Power factor +/- 0.01 Reactive power +/- 2 % Active power +/- 1 % Apparent power +/- 1 % Active energy +/- 1 % Reactive energy +/- 2 % Apparent energy +/- 1 % %
- 50 Hz 60 Hz Hertz (HZ)
- Red
- Class II
- Polycarbonate
- 4 VA at 240 V between phase and neutral
- 1 YEAR
- IP51 front: conforming to IEC 60529 IP30 body: conforming to IEC 60529
- Multi-function meter
- between phase
- -10 60 C Celsius (oC)
Power Meter-METSEEM6436HCL10RS Trade Information
- Paypal, Cash Advance (CA), Cash in Advance (CID), Cheque
- 50 Piece Per Week
- 5 Days
- Yes
- RAIP WITH CARTUN
- Asia
- All India
Product Description
EM6436H monitors active and apparent power or energy consumption, run mode and current. The meter can save up to 10 years of integrated data. Providing Class 1 active energy accuracy per IEC 62053-21 standard, the meter will measure active and reactive energy. Communication protocol is Modbus RTU with RS485 port support. The display has 3 rows 14 mm height, 7 segment 4 digit LED display, can simultaneously show up to 3 parameters. Mechanical dimensions are 96 mm in width, 96 mm in height and 90 mm in depth.
