Safety Relay-BMH1001P16A2A
39937.0 INR/Piece
Product Details:
- Protect Feature Other
- Rated Voltage 480V Volt (V)
- Warranty 1 YEAR
- Rated Current 11.2 A for LXM32.D12N4 11.9 A for LXM32.D18N4 Ampere (amp)
- IP Rating IP54
- Mechanical Life 8 Hours
- Material YES
- Click to View more
X
Safety Relay-BMH1001P16A2A Price And Quantity
- 5 Piece
- 39937.0 INR/Piece
Safety Relay-BMH1001P16A2A Product Specifications
- 800 W for LXM32.D12N4 at 3 A, 400 V, three phase 800 W for LXM32.D12N4 at 3 A, 480 V, three phase 1300 W for LXM32.D18N4 at 6 A, 400 V, three phase 1300 W for LXM32.D18N4 at 6 A, 480 V, three phase
- 3.34kg. Kilograms (kg)
- High Power
- YES
- Servo motor
- 3 PHASE
- 11.2 A for LXM32.D12N4 11.9 A for LXM32.D18N4 Ampere (amp)
- IP54
- 128.6mm (Length) x 100mm (Width) Millimeter (mm)
- 8 Hours
- Other
- BLACK
- Other
- 3.1 Ohm at 20 C
- 480V Volt (V)
- 1 YEAR
Safety Relay-BMH1001P16A2A Trade Information
- Paypal, Cash Advance (CA), Cash in Advance (CID), Cheque
- 30 Piece Per Week
- 5 Days
- Yes
- RAIP WITH CARTUN
- Asia
- All India
Product Description
This product is part of the Lexium 32 range, an offer of motion servo drives for machines from 0.15kW to 7kW. The 10-pole servo motor features a medium moment of inertia with maximum mechanical speed of 6000RPM and parallel keyed shaft without holding brake. It is equipped with a SinCos Hiperface encoder (32768 points/turn) for automatic transmission of data from the servo motor to the servo drive. BMH servo motor is medium inertia motor, it is particularly suitable for high-load applications and allows the movement to be adjusted in a more robust manner. It is a synchronous servo motor with a rated supply voltage of 480V, a continuous stall current of 3.15A and a continuous power of 1.76W. The shaft dimensions are 19mm (Diameter) x 40mm (Length). It is furnished with rotatable right-angled connectors for electrical connection. It is an IP54 rated product. Its dimensions are 128.6mm (Length) x 100mm (Width), centring collar dimensions are 3.5mm (Depth) x 95mm (Diameter) with 115mm circle diameter of the mounting hole. It weighs 3.34kg. This product is compatible with Lexium 32 servo drives. It supports international standard 100mm flange mount with a natural convection cooling system. Encoder gives the absolute position of the motor so that flows can be synchronized and sends data from the servo motor to the servo drive, which provides automatic identification of the motor when the servo drive starts. BMH servo motor with a 3-phase stator and neodymium iron boron (NdFeB) magnets. Casing with RAL 9005 opaque black paint protective coating. 4-point axial mounting flange. Cables and connectors to be ordered separately.
