Soft Starter -ATS48D17Q
37409.2 INR/Piece
Product Details:
- Frequency 60 Hertz (HZ)
- Overheating Protection YES
- Connector Type 1 RJ45
- Phase THREE PHASE
- Rated Voltage 415 Volt (V)
- Operating Temperature 70 Celsius (oC)
- Power Rating 7.5KW
- Click to View more
X
Soft Starter -ATS48D17Q Price And Quantity
- 1 Piece
- 37409.2 INR/Piece
Soft Starter -ATS48D17Q Product Specifications
- THREE PHASE
- 415 Volt (V)
- 70 Celsius (oC)
- 7.5KW
- YES
- 1 RJ45
- 60 Hertz (HZ)
- 60 Hertz (HZ)
- 18 Kilograms (kg)
- Heavy duty industry and pumps
- To the motor delta terminals In the motor supply line
- SOFT STARTER
- 1YEAR
- 17 Ampere (amp)
Soft Starter -ATS48D17Q Trade Information
- Paypal, Cash Advance (CA), Cash in Advance (CID), Cheque
- 50 Piece Per Week
- 3 Days
- Yes
- Asia
- All India
Product Description
This Altistart 48 soft start/soft stop unit is a controller with 6 thyristors used for torque-controlled soft starting and stopping of three-phase asynchronous motors. It offers soft starting and deceleration functions along with machine and motor protection functions, as well as functions for communicating with control systems. It works at a rated supply voltage from 230V to 415V AC and up to 17A rating. Altistart 48 torque control enables starting without mechanical stress and smooth control of hydraulic transitions, with a single acceleration ramp making adjustments is quick and easy, whatever the load. If connected in the motor supply line it is suitable for motors with power rating up to 7.5kW (at 400V) for standards applications and 5.5kW (at 400V) for severe applications. If connected to the motor delta terminals it is suitable for motors with power rating up to 15kW (at 400V) for standards applications and 11kW (at 400V) for severe applications. It weighs 4.9kg and its dimensions are, 160mm wide, 275mm high, 190mm deep. It is designed for use in the most common applications for centrifugal machines, pumps, fans, compressors and conveyors, which are primarily to be found in the construction, food and beverage and chemical industries. It complies with IEC/EN 60947-4-2 standard and is certified CE, UL, CSA, DNV, C-Tick, GOST, CCC, NOM, SEPRO, and TCF. The Altistart 48 is connected directly to the Modbus bus via its RJ45 connector port, It can also be connected to Ethernet, Fipio, Profibus DP and DeviceNet networks via a module (bridge or gateway) to order separately. It is designed to be mounted in vertical position (+/- 10 ) on a panel, thanks to 4 fixing holes. Altistart 48 delivers high performance with its Torque Control System (TCS) for controlled starting and deceleration, an easy integration in enclosures and control systems. This range provides also continual improvement of your machine operation by reducing mechanical or hydraulic stress and limiting energy loss and temperature rise, plus more.
