Variable Speed Drive -ATV340D45N4E

157986.88 INR/Piece

Get a Price/Quote

Product Details:

Operating Temperature 60 Celsius (oC)
Mounting Type WALL MOUNT
Rated Voltage 480 Volt (V)
Connector Type 3 RJ45
Rated Current 88 Ampere (amp)
Overheating Protection YES
Frequency 60 Hertz (HZ)
Click to View more
Share Your Product:

Request to Call Back Send Inquiry

Variable Speed Drive -ATV340D45N4E Price And Quantity

Price 157986.88 INR/Piece
Minimum Order Quantity 1 Piece

Variable Speed Drive -ATV340D45N4E Product Specifications

Frequency 60 Hertz (HZ)
Frequency (MHz) 60
Weight 56.4 Kilograms (kg)
Product Type Variable speed drive
Application Machine
Operating Temperature 60 Celsius (oC)
Input Voltage 380 Volt (V)
Color BLACK
Rated Voltage 480 Volt (V)
Phase THREE PHASE
Warranty 1YEAR
Connector Type 3 RJ45
IP Rating IP20
Rated Current 88 Ampere (amp)
Mounting Type WALL MOUNT
Power Rating 45KW
Output Type Software-configurable voltage AQ1, AQ2: 0...10 V DC impedance 470 Ohm, resolution 10 bits Software-configurable current AQ1, AQ2: 0...20 mA impedance 500 Ohm, resolution 10 bits
Overheating Protection YES
Dimension (L*W*H) 213
Connection Type Control: screw terminal 0.75...1.5 mm /AWG 18...AWG 16 Line side: screw terminal 70...120 mm /AWG 1/0...250 kcmil DC bus: screw terminal 70...120 mm /AWG 1/0...250 kcmil Motor: screw terminal 70...120 mm /AWG 1/0...250 kcmil
Shape RECTANGLE

Variable Speed Drive -ATV340D45N4E Trade Information

Payment Terms Paypal, Cash Advance (CA), Cash in Advance (CID), Cheque
Supply Ability 55 Piece Per Week
Delivery Time 4 Days
Sample Available Yes
Sample Policy Within a certain price range free samples are available
Main Export Market(s) Asia
Main Domestic Market All India

Product Description

This Altivar 340 variable speed drive can feed 3-phase synchronous and asynchronous motors in open and closed loop control. Altivar Machine ATV340 drives are sized heavy duty as standard. It works at a rated power up to 45kW / 60hp and a rated voltage from 380V to 480V AC. ATV340 has been designed to meet the needs of applications for harsh environments, such as vibration, shock and non-conductive dust and where high temperature resistance up to 60 C is needed. This product integrates Modbus serial line communication protocols as standard. This drive features multi-protocol Ethernet embedded, it consists of Ethernet IP and Modbus TCP communication interfaces. it weighs 56.4kg and its dimensions are, 271mm wide, 908mm high, 309mm deep. ATV340 incorporates functions and features suitable for the most common applications, including packaging, material handling, material working, hoisting. It conforms to international standards IEC/EN 61800-5-1 and IEC/EN 61800-3 (immunity and conducted and radiated EMC emissions), IEC 60721-3, IEC 61508, IEC 13849-1. It is also CE, UL, CSA, and TV certified. Accessories and options (encoder interface modules, I/O expansion modules, communication modules, braking resistors, line chokes, additional EMC filters) are available with Altivar Machine ATV340 drives, depending on the drive rating. It is designed to be mounted in vertical position (+/- 10 ) on a panel, thanks to 4 fixing holes. It is fully integrated inside Schneider Electrics EcoStruxure Machine through DTM. It is possible to configure, control, and diagnose ATV340 drives directly in SoMachine and SoMove software by means of the same software brick (DTM).
