ATV610U75N4-variable speed drive, Easy Altivar 610, 7.5kW, 10hp, 380 to 460V, IP20
ATV610U75N4-variable speed drive, Easy Altivar 610, 7.5kW, 10hp, 380 to 460V, IP20

ATV610U75N4-variable speed drive, Easy Altivar 610, 7.5kW, 10hp, 380 to 460V, IP20

Price 35665.6 INR/ Piece

MOQ : 1 Piece

ATV610U75N4-variable speed drive, Easy Altivar 610, 7.5kW, 10hp, 380 to 460V, IP20 Specification

  • IP Rating
  • IP20
  • Connector Type
  • 1 RJ45 (on the remote graphic terminal) for Modbus serial
  • Overheating Protection
  • YES
  • Power Rating
  • 7.5KW
  • Product Type
  • Variable speed drive
  • Application
  • Fan, pump, compressor, conveyor
  • Protection Level
  • IP67
  • Frequency (MHz)
  • 60 Hertz (HZ)
  • Output Type
  • Software-configurable current AQ1, AQ2: 0...20 mA, resolution 10 bits Software-configurable voltage AQ1, AQ2: 0...10 V DC impedance 470 Ohm, resolution 10 bits
  • Weight
  • 5 Kilograms (kg)
  • Rated Voltage
  • 460 Volt (V)
  • Warranty
  • 1 YEAR
  • Input Voltage
  • 380 Volt (V)
  • Phase
  • THREE PHASE
  • Rated Current
  • 14 Ampere (amp)
  • Connection Type
  • Control, screw terminal: 0.5...1.5 mm Line side, screw terminal: 2.5...16 mm Motor, screw terminal: 2.5...16 mm
  • Frequency
  • 60 Hertz (HZ)


ATV610U75N4-variable speed drive, Easy Altivar 610, 7.5kW, 10hp, 380 to 460V, IP20 Trade Information

  • Minimum Order Quantity
  • 1 Piece
  • Payment Terms
  • Paypal, Cash Advance (CA), Cash in Advance (CID), Cheque
  • Supply Ability
  • 34 Pieces Per Week
  • Delivery Time
  • 5 Days
  • Sample Available
  • No
  • Sample Policy
  • Within a certain price range free samples are available
  • Main Export Market(s)
  • Asia
  • Main Domestic Market
  • All India


About ATV610U75N4-variable speed drive, Easy Altivar 610, 7.5kW, 10hp, 380 to 460V, IP20

This Easy Altivar 610 drive is a frequency inverter for three-phase asynchronous motors. It works at a rated supply voltage from 380V to 415V AC. It is suitable for motors with power rating up to 7.5kW / 10hp for applications requiring slight overload (up to 120%). It is suitable for motors with power rating up to 5.5kW / 7.5hp for applications requiring significant overload (up to 150%). It offers a plug & play solution, whereby parameters are preset in the factory to the desired configuration, to help save process control and operating time. It has integrated radio interference input filters in accordance with the EMC standard for variable speed electrical power drive products IEC/EN 61800-3, edition 2, category C3 in environment 1 or 2. It weighs 4.1kg and its dimensions are, 145mm wide, 297mm high, 203mm deep. this drive has been specially designed for standard applications in the market segments water and wastewater and oil and gas and in the domains process and machine management and building management.
