Power Meter-METSEEM6436HCL10NC
3955.0 INR/Piece
Product Details:
- Rated Current 5 A 1 A Ampere (amp)
- Usage & Applications Power monitoring Energy monitoring
- Display Type 8 segments LED
- Power Rating 2 W at 240 V
- Warranty 1 YEAR
- Accuracy Current +/- 0.5 % Voltage +/- 0.5 % Frequency +/- 0.05 % Power factor +/- 0.01 Reactive power +/- 2 % Active power +/- 1 % Apparent power +/- 1 % Active energy +/- 1 % Reactive energy +/- 2 % Apparent energy +/- 1 % %
- Click to View more
X
Power Meter-METSEEM6436HCL10NC Price And Quantity
- 4 Piece
- 3955.0 INR/Piece
Power Meter-METSEEM6436HCL10NC Product Specifications
- Red
- Mechanical dimensions are 96 mm in width, 96 mm in height and 90 mm in depth. Millimeter (mm)
- 5 A 1 A Ampere (amp)
- IP51 front: conforming to IEC 60529 IP30 body: conforming to IEC 60529
- Power monitoring Energy monitoring
- Class II
- IP51 front: conforming to IEC 60529 IP30 body: conforming to IEC 60529
- 44...300 V AC 45...65 Hz 44...300 V DC Volt (V)
- Multi-function meter
- 8 segments LED
- 60 Hz 50 Hz Hertz (HZ)
- 2 W at 240 V
- Polycarbonate
- 1 YEAR
- 35 480 V AC 50...60 Hz between phases 46 277 V AC 50...60 Hz between phase and neutral 277 999000 V AC 50...60 Hz with external VT Volt (v)
- 60 Hz 50 Hz Hertz (HZ)
- Current +/- 0.5 % Voltage +/- 0.5 % Frequency +/- 0.05 % Power factor +/- 0.01 Reactive power +/- 2 % Active power +/- 1 % Apparent power +/- 1 % Active energy +/- 1 % Reactive energy +/- 2 % Apparent energy +/- 1 % %
- 300 g Grams (g)
- -10 60 C Celsius (oC)
- 3-phase
Power Meter-METSEEM6436HCL10NC Trade Information
- Paypal, Cash Advance (CA), Cash in Advance (CID), Cheque
- 50 Piece Per Week
- 5 Days
- Yes
- RAIP WITH CARTUN
- Asia
- All India
Product Description
EM6436H monitors active and apparent power or energy consumption, run mode and current. The meter can save up to 10 years of integrated data. Providing Class 1 active energy accuracy per IEC 62053-21 standard, the meter will measure active and reactive energy. The display has 3 rows 14 mm height, 7 segment 4 digit LED display, can simultaneously show up to 3 parameters. Mechanical dimensions are 96 mm in width, 96 mm in height and 90 mm in depth.
